All In One System Large Capacity Portable LiFePO4 Battery For Household Energy Storage
  • All In One System Large Capacity Portable LiFePO4 Battery For Household Energy Storage
  • All In One System Large Capacity Portable LiFePO4 Battery For Household Energy Storage
  • All In One System Large Capacity Portable LiFePO4 Battery For Household Energy Storage
  • All In One System Large Capacity Portable LiFePO4 Battery For Household Energy Storage
  • All In One System Large Capacity Portable LiFePO4 Battery For Household Energy Storage

All In One System Large Capacity Portable LiFePO4 Battery For Household Energy Storage

Place of Origin MADE IN CHINA
Brand Name BeLYEnergy
Certification CE,ROHS,MSDS,UN38.3
Model Number BLYDN-5KW-10.75KWH
Product Details
Dimension:
795 * 515 * 480 Mm
Material:
Metal Sheet
Weight:
120kgs
Cycle Life Time:
More Than 6000 Cycles
Nominal Capacity:
210Ah
Application:
Home Energy Storage
Highlight:

All In One Energy Storage System

,

Energy Storage System 5kwh 10kwh

,

Household Energy Storage System

Payment & Shipping Terms
Minimum Order Quantity
10PCS
Price
Negotiable
Packaging Details
UN Carton
Delivery Time
2~3weeks for samples; 4~6weeks for mass production
Payment Terms
T/T, L/C, Western Union, MoneyGram
Supply Ability
1000PCS per month
Product Description

All In One System Large Capacity Portable LiFePO4 Battery For Household Energy Storage



1. General Information



Bely All-In-One Series is specifically designed for powering various household appliances such as TVs, laptops, stereos and desktop computers. It is a backup power providing uninterrupted power supply that equipped with a Grade A LiFePO4 battery pack with smart BMS inbuilt and a pure sine wave solar inverter rated at 5kW. There are multiple AC output ports for multiple devices, which will be an ideal portable power house for all your household appliances.





     2 .Description of All-In-One Series



All-In-One Energy Storage System is a powerful and efficient solar energy system designed to provice clean and reliable electricity. This innovative system integrates all the components required for solar power generation into a single, compact unit, including an inverter, LiFePO4 battery pack and a charge controller. Its compact design saves space. Additionally, its plug and play functionality and free online monitoring enable faster installations and easier maintenance with minimized effort.



     3. Battery Specification



INVERTER
Rated Power 5000W
Surge Power 10000W
Output Voltage Waveform Pure Sine Wave
Output Voltage Regulation 220/230/240Vac±5%
Output Frequency 50Hz / 60Hz (±0.1%)
Peak Efficiency 90~93%
Transfor Time (Adjustable) 10ms for Computer Equipment,20ms for Household Equipment
Overload Ability Battery Mode: 21s@105%-150% Load 11s@150%-200% Load      400ms@>200% Load
PV INPUT
Max Solar Power Input 5000W
MPPT Tracking Range 60-600VDC
Best VMP Working Range 300-400VDC
MAX PV Input Voltage 500VDC
MAX PV Input Current 18A
AC CHARGE
Charging current @ Nominal Input Voltage 20A
LITHIUM BATTERY
Energy 10752Wh
Nominal Voltage 51.2V
Battery Capacity 210Ah
Constant Charging Voltage 58.4VDC
Float Charging Voltage 51.2VDC
Storage Temperature -20~55°C
Charge Temperature 0~55°C
Discharge Temperature -20~60°C
DIMENSION
Machine Dimension (W*H*D)(mm) L795*W515*H480
Standard Warranty Inverter: 2 years ; Lithium battery: 3 years



      4. Benefits



All In One Energy Storage System offers a comprehensive solution for efficient energy management and storage, with a range of benefits for both residential and commercial applications.



Convenience

By combining multiple components into a single unit, installation and maintenance are simplified, saving time and effort.



Space-saving

All components are integrated into a compact unit, saving space compared to having separate components scattered around.



Efficiency

Integrated systems are designed to work seamlessly together, optimizing energy storage and distribution efficiency.



Cost-effective

While the initial cost might be higher than individual components, the overall cost can be lower due to reduced installation and maintenance expenses.



Scalability

Many All In One Energy Storage Systems are designed to be easily expandable, allowing you to increase your energy storage capacity as needed.



Monitoring and Control

Integrated systems often come with advanced monitoring and control features, providing real-time data on energy usage and storage.



Backup Power

These systems can often provide backup power during outages, ensuring a continuous power supply.



Environmental Benefits

By storing excess energy from renewable sources, you reduce reliance on non-renewable energy sources, contributing to a greener and more sustainable energy system.



All In One System Large Capacity Portable LiFePO4 Battery For Household Energy Storage 0

All In One System Large Capacity Portable LiFePO4 Battery For Household Energy Storage 1



5. Application Scenario



All In One System Large Capacity Portable LiFePO4 Battery For Household Energy Storage 2



All In One System Large Capacity Portable LiFePO4 Battery For Household Energy Storage 3
