Caravans UPS 12V 100AH LiFePO4 Lithium Battery With Heating Elements Bluetooth
  • Caravans UPS 12V 100AH LiFePO4 Lithium Battery With Heating Elements Bluetooth
  • Caravans UPS 12V 100AH LiFePO4 Lithium Battery With Heating Elements Bluetooth

Caravans UPS 12V 100AH LiFePO4 Lithium Battery With Heating Elements Bluetooth

Place of Origin China
Brand Name Bely
Certification CE, MSDS, UN38.3, ROHS
Model Number BLY-LFP-12V100AHBLH
Product Details
Type:
LiFePO4
Nominal Voltage:
12.8V
Nominal Capacity:
100Ah
Cycle Life:
≥3000 Times
Warranty:
2 Years
Application:
RV, Camper, Solar Storage, Marine
Weight:
12kgs
Color:
Blak Or Customized
Battery Type:
Prismatic
Oem/odm:
Accepatable
Connector:
Copper Pillar
Battery Dimension:
355mm X 175mm X 188mm
IP Class:
IP65
High Light:

100AH LiFePO4 Lithium Battery

,

UPS 12V LiFePO4 Lithium Battery

,

UPS lithium caravan leisure battery

Payment & Shipping Terms
Minimum Order Quantity
50PCS
Price
Negotiable
Packaging Details
Carton
Delivery Time
7-14 days for samples, 35-60 days for mass production
Payment Terms
L/C, D/A, D/P, T/T, Western Union
Supply Ability
100000pcs per month
Product Description

Heating Elements Bluetooth LiFePO4 Lithium Battery 12V 100AH Marine Lithium Battery For Caravans / UPS



Are you looking for the the best LiFePO4 battery?

Bely has you covered offering the latest in high performance lithium batteries for your needs!
lithium battery up to 5x the lifespan of standard lead-acid battery. This series is temperature resistant and lightweight, and
offers a higher charge/discharge cycles, about 3,000 cycles at 90% DOD (depth of discharge). LiFePO4 cathode is intrinsically safer than the LiCo02 or the manganese cathode. Our wide variety of standard and high performance batteries ensure we have what you need, when you need it.



Features and advantages

Higher capacity for the same physical size of lead acid

cycle.can be discharged to 90% vs lead acid recommended 50% depth of discharge.

Lighter weight. About 1/3 the weight of lead acid.

Maintenance free or automatic repair

Our lifepo4 batteries have a built in BMS

Safer performance.Lifepo4 catains no harmful material.Our batteries also pass different safety tests.

Longer life.Our battery has more than 3000 cycle times and there is a 2-year warranty

Bluetooth function can be added.So you can read the battery status by computer or mobile app.

High discharging current capacity, working well with most of inverters in the market.

Peak discharging current 200A ≤20seconds.

Prismatic cells UL1642& UN38.3 & ICE62619 certified, packs CE & UN38.3 & MSDS..

Series & Parallel connections are available.

Low temperature (charged heating) are available, composed of two heating elements to ensure normal charging at -30℃.

OEM & ODM service are availble.

Caravans UPS 12V 100AH LiFePO4 Lithium Battery With Heating Elements Bluetooth 0



1. General Information

This specification defines the performance of rechargeable LiFePO4 battery pack BLY-LFP-12V 100AHBLH manufactured by Shenzhen Bely Energy Technology Co., Ltd. describes the type, performance, technical characteristics, warning and caution of the battery pack. The battery pack supports Bluetooth communication function. Through Android and IOS APP, the battery status and information can be read. Especially due to the Android system’s openness, different smartphone manufacturer will have their own different Bluetooth hardware version and customized feature Android systems. So the APP may not work well on some smartphones (with Android system) due to the compatible issue. It is necessary for the customer to confirm whether the phone is compatible with the APP.

1.1 BMS

BATTERY MANAGEMENT SYSTEM

The battery Management system (BMS) installed in every battery ensures that the battery in the event of under voltage or overload switches off and automatically again turns on as soon as the problem is resolved.

1.2 EASY REPLACEMENT THE EXISTING BATTERY

The dimensions of the housing are identical with the most common AGM, lead acid or GEL batteries. With optionally available round poles can also use existing pole, terminals can be reused. An exchange the battery holder or a change the loading structure is not necessary.

1.3 APPLICATION AREAS

The areas of application of this battery are specifically for the stationary or mobile area. Lithium batteries are diverse. Especially Mobile homes, solar, e-boats, electric scooters, golf carts or electronic-mobiles / wheelchairs and cleaning machines will always be more often equipped with it.

1.4 BATTERY CHARGING

Use the suitable lithium battery charger. Waiting until the battery is fully charged.

1.5 PERFORMANCE / EFFICIENCY

A BeLY LiFePo4 battery can do more than 96% of the energy made available directly to save. A 100% utilization of the existing capacity takes place with the same output voltage.



2. Battery Specification



No. Specification Remarks
1 Composed type 4S2P 50Ah/3.2V
2 Nominal capacity 100 Ah 14.6V cut-off capacity
3 Minimum capacity >100Ah
4 Normal voltage 12.8V Working voltage
5 Discharge cut-off voltage 11.6V
6 Charging voltage 14.6V
7 Internal Impedance <10mΩ
8 Consistent attributes Charging ending( 14.6V fully charge) single cell voltage difference <50mV Recorded is the instantaneous voltage difference at the end of the charge
9 Discharging ending (Voltage 11.6V) single cell voltage difference <50mV Recorded is the instantaneous voltage difference at the end of the discharge
10 Max. continuous charging current 100A
11 Max. continuous discharging current 150A
12 Peak discharging current 200A (<20seconds)
13 Working temperature Charging: -30-50°C 60±25%R.H. Bare Cell (Single cell storage humidity range )
Discharging: -20-60°C
14 Storage temperature Less than 12 months: -20~25 °C 60±25%R.H. at the shipment state (Humidity range at shipment status)
Less tlian 3 months: -20~40 °C
Less than 7 days: -20~60 °C
15 Size/ mm 355*175*190±0.5mm ABS (Outer dimensions of shell including terminal)
16 Positive and negative Terminal Copper pillar
17 Net Weight <17Kg
18 Shipped goods Electricity 50% electricity
19 Package Carton



3. Battery Management System (BMS)



The battery management system (BMS) built into each battery ensures that the battery switch off in the event of under voltage or overload and automatically again turns on as soon as the problem is resolved.

- Protection of the cell against under voltage by switching off the load in good time.

- Protection of the cell against over voltage by reducing the charging current or switching off the charging process.

- Shutting down the system in the event of excess temperature.

- Charging of the battery is stopped in case of under temperature.



5. Application



Motohomes, caravans and RV

Photovoltaics, solar systems and renewable energies

High performance traction/storage battery

Fishing, electric boat motors and sonar

Mobile power supply, camping and leisure

Emergency power supply/UPS

Caravans UPS 12V 100AH LiFePO4 Lithium Battery With Heating Elements Bluetooth 1

6.  Storage and transportation

The battery must be packed and protected well during transport.

The lithium battery must be transported according to the rules for transport, these should always be followed (transportation code UN3480/UN38.3).

Never lift the battery by the terminals, only by the handles.

The battery should be stored in temperatures from -10℃ to +30℃. During transport, the battery should be about 50-60% charged.

The battery should be charged every three months to keep it active so that it always works maximum.



7. Important instructions



Do not open the LiFePO4 battery without consulting the dealer. Unauthorized opening of the battery voids the manufacturer's warranty.

▪ Only use the battery for the application for which it is intended.

▪ Do not short-circuit the LiFePO4 battery. The cable connections to the consumers must go through a backup to be protected.

▪ Installation and maintenance may only be carried out by qualified specialists.

▪ Do not expose to permanent direct sunlight. Protect from the effects of heat. Temperatures above +60 ° C can damage the battery.

▪ Use only compatible chargers. The battery is in a longer storage of all disconnect devices.

▪ Pay attention to proper assembly.

▪ Avoid damage of any kind, for example by falling, drilling, etc. (Risk of short circuit).

▪ Always keep the battery dry and clean.

▪ Note the plus (+) and minus (-) markings on the LiFePO4 battery and the device and pay attention to the correct polarity.

▪ The cycle capacity may vary due to the change in the working temperature and the charge and discharge rate differ from the nominal capacity.

▪ Suitable for parallel connection maximum four batteries (If need series connection, the BMS should be customized with higher cost).

Before connecting, bring to the same charge level. Batteries from different manufacturers or different types should not be interconnected.



7. Install the LiFePO4 battery



Lithium LiFePo4 batteries are heavy. Make sure it is adequate and safe attach and always use the appropriate transport equipment.

In an accident unsecured, batteries could become a projectile! Always take carefully with lithium batteries.

Make absolutely sure that the LiFePO4 battery is not connected with reversed polarity.

Should the battery be connected incorrectly, the BMS electronics will be irreparably damaged and must be replaced with a new BMS board. This is not a warranty case.
