24 Volt 40Ah LiFePo4 Battery Rechargeable Li Ion Energy Storage Battery Pack

24 Volt 40Ah LiFePo4 Battery Rechargeable Li Ion Energy Storage Battery Pack

  • 24 Volt 40Ah LiFePo4 Battery Rechargeable Li Ion Energy Storage Battery Pack
  • 24 Volt 40Ah LiFePo4 Battery Rechargeable Li Ion Energy Storage Battery Pack
24 Volt 40Ah LiFePo4 Battery Rechargeable Li Ion Energy Storage Battery Pack
Product Details:
Place of Origin: China
Brand Name: Bely
Certification: CE, MSDS, UN38.3,ROHS
Model Number: BLY-LFP-24V40AH
Payment & Shipping Terms:
Minimum Order Quantity: 10pcs
Price: Negotiable
Packaging Details: Carton
Delivery Time: 7-14 days for samples, 35-60days fpr mass production
Payment Terms: L/C, D/A, D/P, T/T, Western Union
Supply Ability: 100000pcs per month
Contact Now
Detailed Product Description
Type: LiFePO4 Nominal Voltage: 25.6V
Nominal Capacity: 40Ah/1024Wh Cycle Life: >2000cycles
Weight: 10KGS Dimension: 275mm X 106mm X 223mm
Color: Black Or Customized Warranty Time: 2 Years
Oem/odm: Accepatable Protection Class: IP65
High Light:

24 Volt 40Ah LiFePo4 Battery

,

40Ah LiFePo4 Battery Rechargeable

,

Li Ion Energy Storage Battery Pack

2 Years Warranty 24V LiFePo4 Battery 24V 40Ah Rechargeable Li Ion Battery Pack

For consumer electronics / energy storage



Are you looking for the the best LiFePO4 battery?

Bely has you covered offering the latest in high performance lithium batteries for your needs!
lithium battery up to 5x the lifespan of standard lead-acid battery. This series is temperature resistant and lightweight, and
offers a higher charge/discharge cycles, about 2,000 cycles at 80% DOD (depth of discharge). LiFePO4 cathode is intrinsically safer than the LiCo02 or the manganese cathode. Our wide variety of standard and high performance batteries ensure we have what you need, when you need it.



Feature

  • Superior Safety: Lithium Iron Phosphate chemistry eliminates the risk of explosion or combustion due to high impact overcharging or short circuit situation.
  • High power: Delivers twice power of lead acid battery, even high discharge rate, while maintaining high energy capacity wider temperature range: -20℃~60℃.
  • Long cycle life: offers up to 20 times longer cycle life and 5 times longer/calendar life the lead acid battery, helping to minimize replacement cost and reduce total cost of ownership.
  • Lighter weight: About 40% of the weight of a comparable lead acid battery. A “dron in”replacement for lead acid batteries.
  • Superior Safety: Lithium Iron Phosphate chemistry eliminates the risk of explosion or combustion due to high impact, overcharging or short circuit situation.
  • Increased Flexibility: Modular Design enables deployment of up to up to ten battery in parallel.
  • Energy density is high. The volume and weight of lithium battery is 1/3 to 1/4 of the traditional lead acid battery with the same capacity.
  • Energy conversion rate is 15% higher than that of a traditional lead acid battery, the advantage of energy saving is obvious. Self-discharge rate < 2% per month.
  • Higher discharge rate, faster charging and discharging When there is a need for backup power supply for a period of 10 hours or less, we could reduce up to 50% of the capacity configuration, comparing to lead acid battery.
  • Broad temperature adaptability. Products perform well at a temperature of -20°C to 60°C, without air conditioning system.
  • High security. Our lithium battery is safe, electrochemical materials are stable, no fire or explosion under extreme conditions such as high temperature, short circuit, drop impact, piercing, etc
  • Cycle durability for a single cell is 2000 cycles 100% DOD, which is 3 to 4 times more than the cycle durability of a traditional lead acid battery.



Specification of Lifepo4 Battery 24V 40AH

Specification Parameter Remarks
Nominal Voltage 25.6V
 Capacity 40Ah/1024Wh
Physical Dimension 275mm x 106mm x 223mm
Weight 10KGS
Electrical Discharge Voltage  25.6V
Charge Voltage 25.6~29.4V
Charging Current 30A
Discharging Current 40A
Others Charging Temperature Range 0~55℃
Discharging Temperature Range -20~60℃
Storage Temperature Range -20~60℃
Cycle Life >2000Cycles
Internal Impedance <20mΩ
Battery Cells Type Prismatic
Connector Copper pillar
Material ABS(anti-UV)
Life time @+25℃ 10 years



Battery Management System(BMS)

The battery management system (BMS) built into each battery ensures that the battery switch off in the event of under voltage or overload and automatically again turns on as soon as the problem is resolved.

- Protection of the cell against under voltage by switching off the load in good time.

- Protection of the cell against over voltage by reducing the charging current or switching off the charging process.

- Shutting down the system in the event of excess temperature.

- Charging of the battery is stopped in case of under temperature.



APPLICATION AREAS

Suitable for RV, Caravan, Marine, Camper, Electric scooter, Golf Carts, Power wheels, Trolling motor, Tool trailer, Backup power supply, Solar, off-grid, etc.



24 Volt 40Ah LiFePo4 Battery Rechargeable Li Ion Energy Storage Battery Pack 0

Install the LiFePO4 battery

Lithium LiFePo4 batteries are heavy. Make sure it is adequate and safe attach and always use the appropriate transport equipment.

In an accident unsecured, batteries could become a projectile! Always take carefully with lithium batteries.

Make absolutely sure that the LiFePO4 battery is not connected with reversed polarity.

Should the battery be connected incorrectly, the BMS electronics will be irreparably damaged and must be replaced with a new BMS board. This is not a warranty case.



FAQ:

Q1. Can I have a sample order?

A. Yes, we welcome sample order to test and check quality.



Q2. Do you have any MOQ limit?

A.Yes, we have MOQ for mass production, it depends on the different part numbers. 1~10pcs sample order is available. Low MOQ, 1pc for sample checking is available.



Q3. How to proceed with an order?

A. Firstly let us konw your requirements or application. Secondly, we quote according to your requirements or our suggestions. Thirdly customer confirms the samples and places a deposit for formal order. Fourthly we arrange the production.



Q4. Is it OK print my logo on the product?

A. Yes. Please inform us formally before our production and confirm the design firstly based on our sample.



Q5. Which certificates do you have?

A. We have CE/FCC/ROHS/UN38.3/MSDS ... etc.



Q6. How about warranty?

A. 2 years warranty. Enable to prolong.
